Test System

• Temperature Humidity Test

  Equipment: Programmable temperature and

  humidity tester chamber

  Condition: T_a=85℃, 85%RH, 168Hrs

• Thermal Cycling Test

  Equipment: Thermal shock test chamber

  Condition: T_a=-55 ℃ 15 min,

            T_a=150 ℃ 15 min,

            T_a=25 ℃ 5 min, 10cycles




• High and Low Temperature Test

  Equipment: high low temp test chamber

  Condition: T_a=150℃±5℃, 24Hrs

            T_a=-55℃±5℃, 24Hrs

• Solderability Test

  Equipment: PB free soldering stove

  Condition: T_a=260±5℃, 10 Sec

            T_a= 350±10℃, 3.5 Sec




• Electrostatic Discharge Test

  Equipment: ESD tester

  Condition: T_a=10~35℃,

                   30~60%RH




• Pressure Cooker Test

  Equipment: PCT chamber

  Condition: T_a=130℃, 15Psi,

                   85%RH, 24Hrs

• Intermittent Operational Life

  Equipment: Multifunctional comprehensive aging system

  Condition: ΔT_j≥100, T_a=25℃,

            t(on)=t(off)=5 min,

            1000 cycles.




• High Temperature Reverse Bias Test

  Equipment: High-temp reverse bias aging system Condition: T_a=125℃/150℃, 85%RH,

            V=100%V_R, 48Hrs
